How Big is 18g Wire with Shielding? Understanding Gauge, Diameter, and Shielding
When dealing with 18 gauge (18g) wire, especially with shielding, understanding its dimensions is crucial for various applications. This guide will clarify the size of 18g wire and explain the impact of shielding on its overall dimensions.
Understanding Wire Gauge:
Wire gauge is a standardized system that inversely measures wire diameter. A lower gauge number indicates a thicker wire, while a higher gauge number indicates a thinner wire. 18g wire is relatively common in electronics and small-scale projects.
Diameter of 18g Wire:
The nominal diameter of unshielded 18g wire is approximately 1.02 mm or 0.040 inches. However, this can vary slightly depending on the manufacturer and the specific material used (e.g., copper, copper-clad aluminum).
What is Shielding and How Does it Affect Size?
Shielding in wire is an additional layer of conductive material (often braided copper or aluminum foil) wrapped around the core conductor. This shielding protects the wire from electromagnetic interference (EMI) and radio frequency interference (RFI).
The addition of shielding increases the overall diameter of the wire. The exact increase depends on the type and thickness of the shielding material used. A typical shielded 18g wire might have an outer diameter ranging from 1.5mm to 2.0mm (approximately 0.06 to 0.08 inches). This increase is significant and needs to be considered during installation and routing.
What are the different types of shielding for 18g wire?
Several types of shielding are used for 18g wire, each impacting the overall size differently:
-
Braided Shielding: This is a common type, consisting of interwoven strands of conductive material. It offers good flexibility and EMI/RFI protection. The added diameter is relatively moderate.
-
Foil Shielding: This involves wrapping the wire with a thin layer of conductive foil. It provides excellent shielding but can be less flexible than braided shielding. The diameter increase is usually less than braided shielding.
-
Combination Shielding (Foil & Braid): Combining foil and braid offers the best of both worlds, maximizing EMI/RFI protection while maintaining reasonable flexibility. This results in the largest diameter increase.
It's crucial to consult the specific wire's datasheet or manufacturer specifications to determine the precise dimensions, including the shielded diameter.
How do I find the exact dimensions of my shielded 18g wire?
The most reliable way is to:
- Check the manufacturer's specifications: Look for datasheets or product information online or in the wire packaging.
- Measure the wire directly: Use a caliper or micrometer for an accurate measurement of the outer diameter.
Why is knowing the size of shielded 18g wire important?
Precise dimensions are important for several reasons:
- Routing and Installation: Knowing the diameter ensures proper fitting in connectors, conduits, and other enclosures.
- Space Constraints: Accurate dimensions are crucial for applications with limited space.
- Current Carrying Capacity: While shielding doesn’t directly change the gauge, the increased diameter slightly affects the wire's thermal properties which can indirectly influence its current-carrying capacity. Always consult the manufacturer's specifications for current ratings.
In conclusion, while the unshielded diameter of 18g wire is relatively consistent, adding shielding significantly affects its overall size. Always consult the manufacturer's specifications for precise measurements to ensure proper installation and functionality. Remember to consider the type of shielding used, as it impacts the final diameter.
